Generator Przebiegów Arbitralnych

Kod po stronie przeglądarki

<style>
    textarea {
      font-family: monospace;
    }
    canvas#drawCanvas {
      border: 1px solid #ccc;
      background: #f9f9f9;
      cursor: crosshair;
    }
</style>
<div id="app" class="container">
    <div class="row my-3">
        <div class="col-md-4 mb-3">
            <label for="sampleCount" class="form-label">Próbki</label>
            <input type="number" id="sampleCount" class="form-control" value="64" min="8" max="512">
        </div>
        <div class="col-md-4 mb-3">
            <label for="frequency" class="form-label">Częstotliwość (Hz)</label>
            <input type="number" id="frequency" class="form-control" value="440" min="20" max="2000">
        </div>
        <div class="col-md-4 mb-3">
            <label for="amplitude" class="form-label">Amplituda</label>
            <input type="number" id="amplitude" class="form-control" value="1" step="0.1" min="0" max="2">
        </div>
    </div>

    <ul class="nav nav-tabs" id="modeTabs" role="tablist">
        <li class="nav-item">
            <button id="btnPresetTab" class="nav-link active" data-bs-toggle="tab" data-bs-target="#preset" type="button">Gotowe przebiegi</button>
        </li>
        <li class="nav-item">
            <button class="nav-link" data-bs-toggle="tab" data-bs-target="#harmonics" type="button">Harmoniczne</button>
        </li>
        <li class="nav-item">
            <button class="nav-link" data-bs-toggle="tab" data-bs-target="#custom" type="button">Rysuj własny</button>
        </li>
    </ul>
    <div class="tab-content mt-3">
        <div class="tab-pane fade show active" id="preset">
            <div class="row mb-3">
                <div class="col-lg-3 mb-3">
                    <label for="waveformType" class="form-label">Typ przebiegu</label>
                    <select class="form-select" id="waveformType">
                        <option value="sine">sinusoidalny</option>
                        <option value="triangle">trójkątny</option>
                        <option value="square">prostokątny</option>
                        <option value="sawtooth">piłokształtny</option>
                        <option value="clipped_sine">przycięty sinus</option>
                        <option value="noise">szum</option>
                        <option value="impulse_train">ciąg impulsów</option>
                        <option value="burst">impuls periodyczny</option>
                        <option value="am">AM (modulacja amplitudy)</option>
                        <option value="fm">FM (modulacja częstot.)</option>
                        <option value="dsb">DSB (modulacja dwuwstęg.)</option>
                        <option value="pwm">PWM (wypełnienie)</option>
                    </select>
                </div>
                <div class="col-lg-3 mb-3">
                    <label for="modType" class="form-label">Sygnał modulujący</label>
                    <select id="modType" class="form-select" disabled>
                        <option value="sin">sinus</option>
                        <option value="triangle">trójkąt</option>
                        <option value="square">prostokąt</option>
                        <option value="sawtooth">piła</option>
                    </select>
                </div>
                <div class="col-lg-3 mb-3">
                    <label for="modIndex" class="form-label">Indeks modulacji / Wsp. wyp.</label>
                    <input type="number" id="modIndex" class="form-control" value="0.5" step="0.1" min="0" max="1" disabled>
                </div>
                <div class="col-lg-3 mb-3">
                    <label for="distortion" class="form-label">Zniekształcenie</label>
                    <select id="distortion" class="form-select">
                        <option value="none">Brak</option>
                        <option value="clip">Obcinanie</option>
                        <option value="halfwave">Półfalowe</option>
                        <option value="fullwave">Pełnofalowe</option>
                        <option value="no_bias_tape">Taśma bez podkładu</option>
                        <option value="dc_bias_tape">Taśma prąd podkładu DC</option>
                        <option value="ac_bias_tape">Taśma prąd podkładu AC</option>
                        <option value="trafo_saturation">Nasycenie transformatora</option>
                    </select>
                </div>
                <div class="col-md-3 mb-3">
                    <button class="btn btn-primary" onclick="generateLUT()"><i class="bi bi-cpu"></i> Generuj LUT</button>
                </div>
                <div class="col-md-12 mb-3">
                    <div class="alert alert-warning">
                        <p class="mb-0">Kliknij Generuj LUT po każdej zmianie w polach powyżej.</p>
                    </div>
                </div>
            </div>
        </div>
        <div class="tab-pane fade" id="harmonics" role="tabpanel">
            <div class="mt-3">
                <table class="table table-sm table-bordered align-middle" id="harmonicsTable">
                    <thead>
                        <tr>
                            <th>Nr harmonicznej</th>
                            <th>Amplituda</th>
                            <th>Akcje</th>
                        </tr>
                    </thead>
                    <tbody>
                        <!-- Wiersze będą dodawane dynamicznie -->
                    </tbody>
                </table>
                <button class="btn btn-success btn-sm mb-3" onclick="addHarmonicRow()"><i class="bi bi-plus-circle"></i> Dodaj harmoniczną</button>
                <button class="btn btn-primary btn-sm mb-3" onclick="generateFromHarmonics()"><i class="bi bi-cpu"></i> Generuj LUT</button>
                <div class="alert alert-warning">
                    <p class="mb-0">Kliknij Generuj LUT po każdej zmianie w polach powyżej.</p>
                </div>
            </div>
        </div>
        <div class="tab-pane fade" id="custom">
            <div class="mb-3">
                <div class="mb-2">Narysuj jeden okres przebiegu (kliknij i przeciągnij):</div>
                <canvas id="drawCanvas" width="310" height="150"></canvas>
                <div class="form-text">Lewy brzeg = początek okresu, prawy = koniec. Góra = 1, dół = -1.</div>
            </div>
            <div class="mb-3">
                <div class="alert alert-info">
                    <p class="mb-0">LUT zostanie uaktualniony po zakończeniu rysowania.</p>
                </div>
            </div>
        </div>
    </div>

    <label for="lutOutput" class="form-label">LUT (Look-Up Table)</label>
    <textarea id="lutOutput" class="form-control mb-3" rows="3" readonly></textarea>
    <canvas id="lutChart" height="100"></canvas>
    <canvas id="fftChart" height="100"></canvas>

    <div class="mb-3" id="dcInfo">
    </div>

    <div class="mb-3" id="thdInfo">
    </div>

    <div class="mb-3">
        <button class="btn btn-success me-2 mb-2" onclick="playLUT()"><i class="bi bi-play-fill"></i> Odtwórz</button>
        <button class="btn btn-danger me-2 mb-2" onclick="stopSound()"><i class="bi bi-stop-fill"></i> Zatrzymaj</button>
        <button class="btn btn-warning me-2 mb-2" onclick="exportWAV()"><i class="bi bi-file-earmark-music"></i> Zapisz do WAV</button>
        <button class="btn btn-info me-2 mb-2" onclick="exportLUT()"><i class="bi bi-box-arrow-up"></i> Eksportuj LUT</button>
        <input type="file" id="importLUTInput" accept=".json" hidden onchange="importLUT(event)" aria-label="Wybierz plik JSON">
        <button class="btn btn-info me-2 mb-2" onclick="document.getElementById('importLUTInput').click()"><i class="bi bi-box-arrow-in-down"></i> Importuj LUT</button>
    </div>

</div>

<script src="https://cdn.jsdelivr.net/npm/chart.js"></script>
<script>
    //variables
    let audioCtx;
    let sourceNode;
    let chart;
    let currentSamples = [];

    const canvas = document.getElementById('drawCanvas');
    const ctx = canvas.getContext('2d');
    let drawing = false;
    let drawnPoints = [];
    let lastX = null,
        lastY = null;

    var chartFFT;

    function dft(signal) {
        const X = [];
        const N = signal.length;
        for (let k = 0; k < N; k++) {
            let re = 0,
                im = 0;
            for (let n = 0; n < N; n++) {
                const angle = -2 * Math.PI * k * n / N;
                re += signal[n] * Math.cos(angle);
                im += signal[n] * Math.sin(angle);
            }
            X.push({
                re,
                im
            });
        }
        return X;
    }

    function calculateTHD(magnitudes) {
        const fundamental = magnitudes[1]; // Pomijamy DC (magnitudes[0])
        const harmonics = magnitudes.slice(2); // od 2. harmonicznej wzwyż

        const harmonicPower = harmonics.reduce((sum, val) => sum + val ** 2, 0);
        const thd = Math.sqrt(harmonicPower) / fundamental;

        return thd * 100;
    }

    function generateLUT() {
        const type = document.getElementById('waveformType').value;
        const count = parseInt(document.getElementById('sampleCount').value);
        const modIndex = parseFloat(document.getElementById('modIndex').value);
        const distortion = document.getElementById('distortion')?.value || 'none';
        const samples = [];
        const fc = 5; // nośna
        const fm = 1; // modulująca

        for (let i = 0; i < count; i++) {
            const t = i / count;
            let val = 0;

            // wybór typu sygnału modulującego
            const mType = document.getElementById('modType').value;
            switch (mType) {
                case 'sin':
                    modulator = Math.sin(2 * Math.PI * fm * t);
                    break;
                case 'triangle':
                    modulator = 1 - 4 * Math.abs(Math.round(t - 0.25) - (t - 0.25));
                    break;
                case 'square':
                    modulator = (t % 1) < 0.5 ? 1 : -1;
                    break;
                case 'sawtooth':
                    modulator = 1 - 2 * (t % 1);
                    break;
            }

            switch (type) {
                case 'sine':
                    val = Math.sin(2 * Math.PI * t);
                    // Zastosuj zniekształcenie jeśli wybrane
                    switch (distortion) {
                        case 'clip':
                            val = Math.max(-0.5, Math.min(0.5, val)); // twarde obcinanie
                            break;
                        case 'halfwave':
                            val = Math.max(0, val); // tylko dodatnia część
                            break;
                        case 'fullwave':
                            val = Math.abs(val); // całość dodatnia
                            break;
                        case 'no_bias_tape':
                            // Efekt jak przy braku prądu podkładu: asymetryczne ograniczenie
                            val = val >= 0 ? 0.9 * val : 0.3 * Math.tanh(3 * val);
                            break;
                        case 'dc_bias_tape':
                            const bias = 0.5; // wartość stała przesuwająca sygnał
                            val = Math.tanh(val + bias) - Math.tanh(bias);
                            break;
                        case 'ac_bias_tape':
                            val = Math.tanh(1.0 * val); // łagodna symetryczna saturacja
                            break;
                        case 'trafo_saturation':
                            val = Math.tanh(1.5 * val); // nieliniowość rdzenia
                            break;
                            // brak domyślnej – pozostaw val bez zmian
                    }
                    break;
                case 'triangle':
                    val = 1 - 4 * Math.abs(Math.round(t - 0.25) - (t - 0.25));
                    break;
                case 'square':
                    val = t < 0.5 ? 1 : -1;
                    break;
                case 'sawtooth':
                    val = 2 * t - 1;
                    break;
                case 'clipped_sine':
                    val = Math.sin(2 * Math.PI * t);
                    val = Math.max(-0.5, Math.min(0.5, val)); // Przycięcie
                    break;
                case 'noise':
                    val = 2 * Math.random() - 1;
                    break;
                case 'impulse_train':
                    // Co N/8 próbek impuls (zwraca 1), reszta 0
                    val = (i % Math.floor(count / 8)) === 0 ? 1 : 0;
                    break;
                case 'burst':
                    // Sinus aktywny tylko przez pierwsze 1/8 okresu
                    val = t < 0.125 ? Math.sin(2 * Math.PI * 8 * t) : 0;
                    break;
                case 'am':
                    const A = 0.7;
                    const m = modIndex; // głębokość AM: 0.0–1.0
                    val = A * (1 + m * modulator) * Math.sin(2 * Math.PI * fc * t);
                    break;
                case 'fm':
                    val = Math.sin(2 * Math.PI * fc * t + modIndex * modulator * 2 * Math.PI);
                    break;
                case 'dsb':
                    val = modIndex * modulator * Math.cos(2 * Math.PI * fc * t);
                    break;
                case 'pwm':
                    const duty = modIndex; // duty cycle ∈ [0,1]
                    val = (t % 1) < duty ? 1 : -1;
                    break;

                default:
                    val = 0;
            }

            samples.push(parseFloat(val.toFixed(4)));
        }

        currentSamples = samples;
        updateDisplay(samples);
        updateFFT(samples);
    }

    function playLUT() {
        stopSound();
        const frequency = parseFloat(document.getElementById('frequency').value);
        const amplitude = parseFloat(document.getElementById('amplitude').value);
        const sampleRate = 44100;
        const periodLength = Math.floor(sampleRate / frequency);
        const lut = currentSamples;

        audioCtx = new(window.AudioContext || window.webkitAudioContext)();
        const buffer = audioCtx.createBuffer(1, periodLength, sampleRate);
        const data = buffer.getChannelData(0);

        for (let i = 0; i < periodLength; i++) {
            const phase = (i * lut.length / periodLength) % lut.length;
            const index = Math.floor(phase);
            const frac = phase - index;
            const nextIndex = (index + 1) % lut.length;
            data[i] = amplitude * (lut[index] * (1 - frac) + lut[nextIndex] * frac);
        }

        sourceNode = audioCtx.createBufferSource();
        sourceNode.buffer = buffer;
        sourceNode.loop = true;
        sourceNode.connect(audioCtx.destination);
        sourceNode.start();
    }

    function stopSound() {
        if (sourceNode) {
            sourceNode.stop();
            sourceNode.disconnect();
            sourceNode = null;
        }
        if (audioCtx) {
            audioCtx.close();
            audioCtx = null;
        }
    }

    function updateFFT(samples) {
        const spectrum = dft(samples);
        const N = samples.length;
        const Fs = N; // Zakładamy 1 cykl na N próbek ⇒ Fs = N (1 okres = 1 sekunda)

        // Częstotliwości (do N/2 - jednostronne widmo)
        const freqs = Array.from({
            length: N / 2
        }, (_, i) => i * Fs / N);

        // Amplitudy – skalowanie dla jednostronnego widma
        const magnitudes = spectrum.slice(0, N / 2).map((c, i) => {
            let mag = Math.sqrt(c.re ** 2 + c.im ** 2) / N;
            if (i !== 0) mag *= 2; // tylko dla składowych > 0 Hz
            return mag;
        });

        const thd = calculateTHD(magnitudes);

        drawFFT(freqs, magnitudes);
        doAlerts(magnitudes, thd);
    }

    function drawFFT(freqs, magnitudes) {
        const ctxFFT = document.getElementById('fftChart').getContext('2d');

        if (chartFFT) {
            chartFFT.data.labels = freqs;
            chartFFT.data.datasets[0].data = magnitudes;
            chartFFT.update();
            return;
        }

        chartFFT = new Chart(ctxFFT, {
            type: 'bar',
            data: {
                labels: freqs,
                datasets: [{
                    label: 'FFT (Amplituda)',
                    data: magnitudes,
                    backgroundColor: 'rgba(255, 99, 132, 0.5)',
                    borderColor: 'rgb(255, 99, 132)',
                    borderWidth: 1
                }]
            },
            options: {
                responsive: true,
                scales: {
                    x: {
                        title: {
                            display: true,
                            text: 'Harmoniczna'
                        }
                    },
                    y: {
                        title: {
                            display: true,
                            text: 'Amplituda'
                        }
                    }
                }
            }
        });
    }

    function showAlertTHD(message, type = "info") {
        const alert = `
        <div class="alert alert-${type}" role="alert">
            <p class="mb-0">${message}</p>
        </div>`;
        document.getElementById("thdInfo").innerHTML = alert;
    }

    function doAlerts(magnitudes, thd) {
        document.getElementById('dcInfo').innerHTML = '';
        if (magnitudes[0] > 0.01) {
            document.getElementById('dcInfo').innerHTML =
                '<div class="alert alert-info"><p class="mb-0"><i class="bi bi-info-square"></i> <strong>Informacja:</strong> Wykryto składową stałą DC w widmie – odpowiada zerowej harmonicznej (0 Hz). Jest to normalne przy przebiegach niesymetrycznych (np. wyprostowanych).</p></div>';
        }

        const thdInfo = document.getElementById('thdInfo');
        const presetTabActive = document.getElementById('btnPresetTab').classList.contains('active');
        const wave = document.getElementById('waveformType').value;
        if (presetTabActive && ((wave === 'am') || (wave === 'fm') || (wave === 'dsb')))
        {
            thdInfo.innerHTML = '';
            return;
        }

        let level, message, alertClass;

        if (thd < 1) {
            level = "success";
            message = `THD: ${thd.toFixed(2)}% – Sygnał o bardzo niskim poziomie zniekształceń.`;
        } else if (thd < 5) {
            level = "info";
            message = `THD: ${thd.toFixed(2)}% – Niski poziom zniekształceń, typowy dla systemów audio.`;
        } else if (thd < 15) {
            level = "warning";
            message = `THD: ${thd.toFixed(2)}% – Umiarkowane zniekształcenia. Możliwe efekty nieliniowości.`;
        } else if (thd < 30) {
            level = "danger";
            message = `THD: ${thd.toFixed(2)}% – Wysoki poziom zniekształceń!`;
        } else if (thd < 100) {
            level = "danger";
            message = `<i class="bi bi-exclamation-triangle"></i> THD: ${thd.toFixed(2)}% – Bardzo silne zniekształcenia! Sygnał może być nasycony lub obcięty.`;
        } else {
            level = "danger";
            message = `<i class="bi bi-exclamation-circle"></i> THD przekracza 100%! Oznacza to, że sygnał zawiera więcej energii w harmonicznych niż w tonie podstawowym. Sygnał jest silnie zniekształcony lub niemal całkowicie pozbawiony podstawowej częstotliwości.`;
        }

        showAlertTHD(message, level);
    }

    function updateDisplay(samples) {
        document.getElementById('lutOutput').value = samples.join(', ');
        drawChart(samples);
    }

    function drawChart(data) {
        const labels = [...Array(data.length).keys()];
        if (chart) chart.destroy();
        chart = new Chart(document.getElementById('lutChart'), {
            type: 'line',
            data: {
                labels: labels,
                datasets: [{
                    label: 'LUT',
                    data: data,
                    borderColor: 'teal',
                    tension: 0.3,
                    pointRadius: 2
                }]
            },
            options: {
                responsive: true,
                animation: false,
                scales: {
                    y: {
                        min: -1.5,
                        max: 1.5
                    },
                    x: {
                        display: false
                    }
                },
                plugins: {
                    legend: {
                        display: false
                    }
                }
            }
        });
    }

    function drawFromLUT(lut) {
        ctx.clearRect(0, 0, canvas.width, canvas.height);
        ctx.beginPath();
        ctx.lineWidth = 2;
        ctx.strokeStyle = '#000';
        for (let i = 0; i < lut.length; i++) {
            const x = i / lut.length * canvas.width;
            const y = (1 - (lut[i] + 1) / 2) * canvas.height;
            if (i === 0) {
                ctx.moveTo(x, y);
            } else {
                ctx.lineTo(x, y);
            }
        }
        ctx.stroke();
    }

    function drawPoint(x, y) {
        drawnPoints[x] = y;
        ctx.fillStyle = 'black';
        ctx.fillRect(x, y, 1, 1);
    }

    function generateLUTFromDrawing() {
        const lutSize = parseInt(document.getElementById('sampleCount').value);
        const samples = [];

        for (let i = 0; i < lutSize; i++) {
            const x = Math.floor(i * canvas.width / lutSize);
            let y = drawnPoints[x];

            if (y === undefined) {
                // Brak punktu: domyślnie 0
                y = canvas.height / 2;
            }

            const val = 1 - (y / canvas.height) * 2; // Zamiana Y na [-1, 1]
            samples.push(parseFloat(val.toFixed(4)));
        }

        currentSamples = samples;
        updateDisplay(samples);
        updateFFT(samples);
    }

    function addHarmonicRow(n = '', a = '') {
        const row = document.createElement('tr');
        row.innerHTML = `
            <td><input type="number" class="form-control form-control-sm" value="${n}" min="1" aria-label="Harmoniczna nr. ${n}"></td>
            <td><input type="number" class="form-control form-control-sm" value="${a}" step="0.01" aria-label="Amplituda wartość ${a}"></td>
            <td><button class="btn btn-danger btn-sm" onclick="this.closest('tr').remove()" aria-label="Usuń harmoniczną"><span class="bi bi-x"></span></button></td>
        `;
        document.querySelector('#harmonicsTable tbody').appendChild(row);
    }

    function generateFromHarmonics() {
        const rows = document.querySelectorAll('#harmonicsTable tbody tr');
        const sampleCount = parseInt(document.getElementById('sampleCount').value);
        const lut = new Array(sampleCount).fill(0);

        for (let row of rows) {
            const n = parseInt(row.cells[0].querySelector('input').value);
            const a = parseFloat(row.cells[1].querySelector('input').value);
            if (isNaN(n) || isNaN(a)) continue;

            for (let i = 0; i < sampleCount; i++) {
                const t = i / sampleCount;
                lut[i] += a * Math.sin(2 * Math.PI * n * t);
            }
        }

        // Normalizacja (opcjonalnie)
        const max = Math.max(...lut.map(Math.abs));
        if (max > 0) {
            for (let i = 0; i < lut.length; i++) {
                lut[i] /= max;
            }
        }

        currentSamples = lut;
        updateDisplay(lut);
        drawFromLUT(lut);
        updateFFT(lut);
    }


    function exportWAV() {
        const frequency = parseFloat(document.getElementById('frequency').value);
        const amplitude = parseFloat(document.getElementById('amplitude').value);
        const duration = 2; // sekundy
        const sampleRate = 44100;
        const totalSamples = duration * sampleRate;
        const lut = currentSamples;
        const buffer = new Float32Array(totalSamples);

        for (let i = 0; i < totalSamples; i++) {
            const phase = (i * lut.length * frequency / sampleRate) % lut.length;
            const index = Math.floor(phase);
            const frac = phase - index;
            const nextIndex = (index + 1) % lut.length;
            buffer[i] = amplitude * (lut[index] * (1 - frac) + lut[nextIndex] * frac);
        }

        // Konwersja do WAV
        const wavData = encodeWAV(buffer, sampleRate);
        const blob = new Blob([wavData], {
            type: 'audio/wav'
        });
        const url = URL.createObjectURL(blob);

        const a = document.createElement('a');
        a.href = url;
        a.download = 'waveform.wav';
        a.click();
        URL.revokeObjectURL(url);
    }

    // Pomocnicza funkcja WAV (mono 16-bit PCM)
    function encodeWAV(samples, sampleRate) {
        const buffer = new ArrayBuffer(44 + samples.length * 2);
        const view = new DataView(buffer);

        function writeStr(offset, str) {
            for (let i = 0; i < str.length; i++) {
                view.setUint8(offset + i, str.charCodeAt(i));
            }
        }

        writeStr(0, 'RIFF');
        view.setUint32(4, 36 + samples.length * 2, true);
        writeStr(8, 'WAVE');
        writeStr(12, 'fmt ');
        view.setUint32(16, 16, true);
        view.setUint16(20, 1, true);
        view.setUint16(22, 1, true);
        view.setUint32(24, sampleRate, true);
        view.setUint32(28, sampleRate * 2, true);
        view.setUint16(32, 2, true);
        view.setUint16(34, 16, true);
        writeStr(36, 'data');
        view.setUint32(40, samples.length * 2, true);

        for (let i = 0; i < samples.length; i++) {
            const s = Math.max(-1, Math.min(1, samples[i]));
            view.setInt16(44 + i * 2, s * 0x7FFF, true);
        }

        return view;
    }

    function exportLUT() {
        const lut = currentSamples;
        const blob = new Blob([JSON.stringify(lut, null, 2)], {
            type: 'application/json'
        });
        const url = URL.createObjectURL(blob);

        const a = document.createElement('a');
        a.href = url;
        a.download = 'lut.json';
        a.click();
        URL.revokeObjectURL(url);
    }

    function importLUT(event) {
        const file = event.target.files[0];
        if (!file) return;

        const reader = new FileReader();
        reader.onload = function(e) {
            try {
                const json = JSON.parse(e.target.result);
                if (!Array.isArray(json)) throw new Error("Niepoprawny format LUT");

                currentSamples = json;
                document.getElementById('sampleCount').value = currentSamples.length;

                updateDisplay(currentSamples);
                drawFromLUT(currentSamples);
            } catch (err) {
                alert("Błąd podczas importu LUT: " + err.message);
            }
        };
        reader.readAsText(file);;
    }

    // Obsługa rysowania
    canvas.addEventListener('mousedown', e => {
        drawing = true;
        ctx.clearRect(0, 0, canvas.width, canvas.height); // czyszczenie
        drawnPoints = [];
        lastX = e.offsetX;
        lastY = e.offsetY;
    });

    canvas.addEventListener('mousemove', e => {
        if (!drawing) return;

        const x = e.offsetX;
        const y = e.offsetY;

        ctx.strokeStyle = '#000';
        ctx.lineWidth = 2; // grubsza linia
        ctx.beginPath();
        ctx.moveTo(lastX, lastY);
        ctx.lineTo(x, y);
        ctx.stroke();

        for (let i = lastX; i <= x; i++) {
            drawnPoints[i] = y; // zapamiętaj punkt
        }

        lastX = x;
        lastY = y;
    });

    canvas.addEventListener('mouseup', () => {
        drawing = false;
        generateLUTFromDrawing();
    });

    canvas.addEventListener('touchstart', (e) => {
        e.preventDefault();
        const touch = e.touches[0];
        const mouseEvent = new MouseEvent('mousedown', {
            clientX: touch.clientX,
            clientY: touch.clientY
        });
        canvas.dispatchEvent(mouseEvent);
    }, {
        passive: false
    });

    canvas.addEventListener('touchmove', (e) => {
        e.preventDefault();
        const touch = e.touches[0];
        const mouseEvent = new MouseEvent('mousemove', {
            clientX: touch.clientX,
            clientY: touch.clientY
        });
        canvas.dispatchEvent(mouseEvent);
    }, {
        passive: false
    });

    canvas.addEventListener('touchend', (e) => {
        e.preventDefault();
        const mouseEvent = new MouseEvent('mouseup', {});
        canvas.dispatchEvent(mouseEvent);
    }, {
        passive: false
    });

    // Inicjalizacja domyślnego przebiegu
    generateLUT();

    const waveformType = document.getElementById('waveformType');
    waveformType.addEventListener('change', function(e) {
        e.preventDefault();
        const modType = document.getElementById('modType');
        const modIndex = document.getElementById('modIndex');
        const distortion = document.getElementById('distortion');
        let value = waveformType.value;

        switch (value) {
            case 'sine':
                modType.disabled = true;
                modIndex.disabled = true;
                distortion.disabled = false;
                break;
            case 'am':
                modType.disabled = false;
                modIndex.disabled = false;
                distortion.disabled = true;
                break;
            case 'fm':
                modType.disabled = false;
                modIndex.disabled = false;
                distortion.disabled = true;
                break;
            case 'dsb':
                modType.disabled = false;
                modIndex.disabled = false;
                distortion.disabled = true;
                break;
            case 'pwm':
                modType.disabled = true;
                modIndex.disabled = false;
                distortion.disabled = true;
                break;
            default:
                modType.disabled = true;
                modIndex.disabled = true;
                distortion.disabled = true;
                break;
        }
    });

</script>

Kod po stronie serwera

Licencja

## BSD-3-Clause License Agreement
BSD-3-Clause
Сopyright (c) 2026 Dariusz Rorat

All rights reserved.

Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice,
   this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice,
   this list of conditions and the following disclaimer in the documentation
   and/or other materials provided with the distribution.

3. Neither the name of the copyright holder nor the names of its
   contributors may be used to endorse or promote products derived from
   this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE
FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
