Analiza Obrazu

Kod po stronie przeglądarki

  <style>
    #waveformCanvas {
      width: 100%;
      height: 400px;
      background: #212529;
    }
  </style>

<div id="app">

    <div class="mb-3">
        <label for="type" class="form-label">Wybierz rodzaj analizy</label>
        <select class="form-select" id="type" autocomplete="on">
            <option value="waveY">Waveform Y</option>
        </select>
    </div>

    <div class="mb-3">
      <label for="imageInput" class="form-label">Wybierz obraz JPG</label>
      <input class="form-control" type="file" id="imageInput" accept="image/jpeg">
    </div>

    <canvas id="waveformCanvas"></canvas>
  </div>
  <script>
    const imageInput = document.getElementById('imageInput');
    const canvas = document.getElementById('waveformCanvas');
    const ctx = canvas.getContext('2d');

    imageInput.addEventListener('change', function () {
      const file = this.files[0];
      if (!file) return;

      const img = new Image();
      img.onload = function () {
        // Ustawiamy ukryty tymczasowy canvas
        const tempCanvas = document.createElement('canvas');
        const tempCtx = tempCanvas.getContext('2d');
        tempCanvas.width = img.width;
        tempCanvas.height = img.height;
        tempCtx.drawImage(img, 0, 0);

        const imageData = tempCtx.getImageData(0, 0, img.width, img.height);
        const data = imageData.data;

        // Konfiguracja waveform canvas
        canvas.width = img.width;
        canvas.height = 400;
        ctx.clearRect(0, 0, canvas.width, canvas.height);
        ctx.fillStyle = "#212529";
        ctx.fillRect(0, 0, canvas.width, canvas.height);

        // Dla każdego piksela w poziomie (x)
        for (let x = 0; x < img.width; x++) {
          for (let y = 0; y < img.height; y++) {
            const index = (y * img.width + x) * 4;
            const r = data[index];
            const g = data[index + 1];
            const b = data[index + 2];

            // Prosta jasność: średnia kanałów
            const brightness = 0.299*r + 0.587*g + 0.114*b;

            //new
            const scaled = (brightness / 255) * canvas.height;
            ctx.globalAlpha = 0.1;
            ctx.strokeStyle = '#0dcaf0';
            ctx.beginPath();
            ctx.moveTo(x, canvas.height - scaled + 1);
            ctx.lineTo(x, canvas.height - scaled);
            ctx.stroke();
          }

        }
      };

      img.src = URL.createObjectURL(file);
    });
  </script>

Kod po stronie serwera
